Functional Feature

• Fully compatible with ITU-T G.984.1/2/3/4 and IEEE802.3ah standard

• The product is small in size and light in weight

• Support LOID authentication mode

• Support dying Gasp function

• Support optical link diagnostic function

• Support restoring factory function

• Support IEEE802.1Q protocol

• Support different VLAN mode (transparent, tag, translate, and trunk)

Hardware

 GPON/EPON Port

single fiber

GPON：FSAN G.984.2 standard

EPON：1000BASE-PX20+ symmetric

GPON：2.488Gbps/1.244Gbps downstream/upstream

EPON：1.25Gbps downstream/upstream

Wavelength :

Transmit: 1310nm       Receiver: 1490nm

 Receiving sensitivity :

GPON：-28dBm            EPON：-27dBm

Saturated power :

GPON：-8dBm              EPON：-3dBm

Transmitting power :

GPON：0.5～5dBm     EPON:0～4dBm

Power

Power consumption:<2W

Environmental Specifications

Operating temperature: 0 to 40ºC

Storage temperature: -40 to 85ºC

Opera

Application

Solution：FTTB/ N

Business：Broadband Internet, Camera
